Building a Home Lab SIEM: Wazuh Deployment with Custom Detection Rules

Published: February 2026 Category: Security Operations Reading Time: 18 minutes

Executive Summary

Deployed Wazuh 4.14.2 SIEM across 16-host home lab infrastructure with three log ingestion paths: agent-based, syslog, and JSON file monitoring
Built 60+ custom detection rules covering C2 beaconing, DNS tunneling, DGA domains, port scanning, honeypot lateral movement, and firewall flood patterns
Integrated network IDS (Zeek), honeypot (OpenCanary), and firewall (pfSense) for multi-layer detection
Implemented automated active response that auto-blocks attackers at the firewall when SIEM detects flood patterns
Configured real-time chat alerting via Mattermost webhook for level 8+ events
Documented critical Wazuh gotchas: field match types, srcip limitations, duplicate rule ID behavior, and JSON decoder precedence

Goal

Problem: A security lab without centralized logging is just a collection of devices hoping nothing bad happens. I had 16 hosts generating logs independently - firewall blocks, IDS alerts, honeypot hits, authentication failures - but no unified view. Attackers don't announce themselves; they leave traces across multiple systems. Without correlation and alerting, those traces go unnoticed.

Why it mattered: Home labs are targets. They have public-facing services, they run 24/7, and they're often less hardened than enterprise infrastructure. I needed a SIEM that could detect scanning, brute force, C2 beaconing, and lateral movement - and alert me before an attacker establishes persistence. More importantly, I wanted automated response: if someone floods my firewall, block them without waiting for me to notice.

Scope and Constraints

In Scope

Wazuh server deployment and configuration
Agent deployment across 16 infrastructure hosts
Custom decoders for firewall CSV logs and Zeek JSON
Detection rules for network-layer threats (scanning, tunneling, DGA, C2)
Detection rules for honeypot activity
Detection rules for firewall flood patterns
Active response automation (firewall blocking, SSH brute force response)
Chat integration for real-time alerting

Out of Scope

Wazuh dashboard customization (default dashboards used)
File integrity monitoring rules (P0 improvement)
Windows-specific detection rules (P2 improvement)
Vulnerability scanning module
Threat intelligence feed integration

Key Constraints

No false positive floods - Suppression rules must filter known-good infrastructure traffic
Sub-minute alerting - Critical events must reach chat within seconds
Automated blocking must be safe - Can't auto-block legitimate infrastructure IPs
Rules must be maintainable - Clear naming, documented rule IDs, logical grouping

Tools and References

Tool	Role in This Project
Wazuh 4.14.2	SIEM platform - log aggregation, correlation, detection rules, active response
Zeek	Network IDS - connection logs, DNS queries, SSL certificates, behavioral notices
OpenCanary	Honeypot - fake services that alert on any connection (SSH, HTTP, MySQL, FTP)
pfSense	Firewall - perimeter logging, block table for active response
Mattermost	Team chat - webhook receiver for real-time alerting
Proxmox	Hypervisor - hosts VMs and containers running monitored services

References:

Approach

Phase 1: Wazuh Server Deployment

What I did: Deployed Wazuh 4.14.2 on a dedicated VM with sufficient resources for log ingestion and rule processing. Configured three ingestion paths: agent listener (1514/tcp), syslog receiver (514/udp), and local JSON file monitoring for Zeek logs.

Why: Different log sources require different collection methods. Agents provide the richest data (file integrity, command monitoring), syslog handles devices that can't run agents (firewall), and file monitoring handles structured logs from the IDS sensor.

Phase 2: Agent Deployment

What I did: Installed Wazuh agents on all 16 infrastructure hosts: Proxmox hypervisors, LXC containers, bare metal servers, Windows desktop, mail server, NAS, wiki, automation platform. Configured firewall to send syslog, and set up JSON log shipping from the Zeek sensor.

Why: Full coverage is the foundation. An unmonitored host is a blind spot where attackers can operate freely. Even "low value" hosts like the wiki can be pivot points for lateral movement.

Phase 3: Custom Decoder Development

What I did: Built a custom decoder for firewall CSV logs using pcre2 regex to extract interface, action, direction, source IP, destination IP, and ports. For Zeek logs, I used the built-in JSON decoder and differentiated log types by field presence in rules.

Why: The firewall logs arrive as comma-separated values - not JSON, not syslog format. Without a custom decoder, Wazuh can't extract the fields needed for detection rules. Zeek logs are JSON but have different schemas per log type (conn.log vs dns.log vs ssl.log).

Phase 4: Detection Rule Development

What I did: Created 60+ rules across three rule files: network IDS detection (Zeek), firewall pattern detection (pfSense), and honeypot alerting (OpenCanary). Rules cover port scanning, DNS tunneling, DGA domains, C2 beaconing, self-signed certificates, honeypot probes, and firewall floods.

Why: Out-of-the-box Wazuh rules focus on common attacks against common services. My environment has specific detection needs: Zeek notices for long connections, OpenCanary honeypot alerts, and firewall flood patterns that indicate scanning or DDoS.

Phase 5: False Positive Suppression

What I did: Added level-0 suppression rules for known infrastructure traffic: CDN provider subnets, VPN relay IPs, cloud service ranges, and reverse DNS lookup sources. Created local LAN traffic suppression for firewall rules.

Why: Without suppression, legitimate traffic floods the alert console. Cloudflare tunnel connections trigger "long connection" alerts. VPN relays trigger DNS tunneling rules. CDN queries look like DGA. Suppression rules maintain signal-to-noise ratio.

Phase 6: Active Response Configuration

What I did: Configured two active response scripts: (1) firewall auto-block that adds attacking IPs to the block table when SIEM detects flood patterns, and (2) SSH brute force blocker that drops attacker IPs via iptables for 45 days.

Why: Detection without response is just observation. If the SIEM detects a flood attack, waiting for human intervention gives the attacker time. Automated blocking stops the attack immediately.

Phase 7: Chat Integration

What I did: Configured Mattermost webhook integration to receive all level 8+ alerts in JSON format for real-time notification.

Why: I'm not watching the SIEM dashboard 24/7. Chat notifications ensure I see critical alerts within seconds, even when away from the security console.

Implementation Notes

Custom Firewall Decoder (Sanitized)

<!-- /var/ossec/etc/decoders/local_decoder.xml -->
<decoder name="pfsense-filterlog">
  <prematch>filterlog:</prematch>
</decoder>

<decoder name="pfsense-filterlog-fields">
  <parent>pfsense-filterlog</parent>
  <regex type="pcre2">filterlog:\s*(\d+),.*?,.*?,.*?,(\w+),(\w+),(\w+),.*?,.*?,.*?,.*?,.*?,(\d+\.\d+\.\d+\.\d+),(\d+\.\d+\.\d+\.\d+),(\d+),(\d+)</regex>
  <order>rule_number,interface,action,direction,srcip,dstip,srcport,dstport</order>
</decoder>

Note: The actual regex is more complex to handle IPv6 and edge cases. This shows the pattern.

Zeek Log Differentiation in Rules (Sanitized)

<!-- Zeek logs use built-in JSON decoder - differentiate by field presence -->

<!-- Connection logs have conn_state field -->
<rule id="100100" level="3">
  <decoded_as>json</decoded_as>
  <field name="conn_state">\.+</field>
  <description>Zeek: Connection log entry</description>
</rule>

<!-- DNS logs have qtype_name field -->
<rule id="100110" level="3">
  <decoded_as>json</decoded_as>
  <field name="qtype_name">\.+</field>
  <description>Zeek: DNS query log entry</description>
</rule>

<!-- SSL logs have validation_status field -->
<rule id="100120" level="3">
  <decoded_as>json</decoded_as>
  <field name="validation_status">\.+</field>
  <description>Zeek: SSL certificate log entry</description>
</rule>

DNS Tunneling Detection (Sanitized)

<!-- Detect suspiciously long DNS queries (potential tunneling) -->
<rule id="100115" level="8">
  <if_sid>100110</if_sid>
  <field name="query" type="pcre2">^[a-zA-Z0-9-]{50,}\.</field>
  <description>Zeek: Possible DNS tunneling - query length exceeds 50 characters</description>
  <group>dns_tunneling,attack</group>
</rule>

<!-- Suppression for known CDN/cloud services with long subdomains -->
<rule id="100116" level="0">
  <if_sid>100115</if_sid>
  <field name="query" type="pcre2">\.(cloudfront|akamaized|fastly|azureedge)\.</field>
  <description>Suppress: Known CDN long subdomain pattern</description>
</rule>

Firewall Flood Detection (Sanitized)

<!-- Base rule: track individual blocks -->
<rule id="100200" level="3">
  <decoded_as>pfsense-filterlog</decoded_as>
  <field name="action">block</field>
  <description>pfSense: Blocked traffic</description>
</rule>

<!-- High-volume blocking from same source -->
<rule id="100205" level="10" frequency="20" timeframe="30">
  <if_matched_sid>100200</if_matched_sid>
  <same_source_ip />
  <description>pfSense: High-volume blocks from same source (20 in 30s)</description>
  <group>firewall_flood,attack</group>
</rule>

<!-- Flood pattern - triggers active response -->
<rule id="100206" level="12" frequency="50" timeframe="60">
  <if_matched_sid>100200</if_matched_sid>
  <same_source_ip />
  <description>pfSense: Flood pattern detected (50 in 60s) - triggering active response</description>
  <group>firewall_flood,active_response</group>
</rule>

Honeypot Detection (Sanitized)

<!-- Any honeypot connection is suspicious -->
<rule id="100300" level="12">
  <decoded_as>json</decoded_as>
  <field name="dst_host" type="pcre2"><HONEYPOT_IP></field>
  <description>Honeypot: Connection attempt detected</description>
  <group>honeypot,lateral_movement</group>
</rule>

<!-- SSH to honeypot is critical -->
<rule id="100301" level="13">
  <if_sid>100300</if_sid>
  <field name="dst_port">22</field>
  <description>Honeypot: SSH connection attempt - likely lateral movement</description>
  <group>honeypot,ssh,lateral_movement</group>
</rule>

<!-- Multi-service probe (attacker scanning the honeypot) -->
<rule id="100310" level="14" frequency="3" timeframe="300">
  <if_matched_sid>100300</if_matched_sid>
  <same_source_ip />
  <description>Honeypot: Multi-service probe detected (3+ services in 5 min) - CRITICAL</description>
  <group>honeypot,scanning,critical</group>
</rule>

Active Response Configuration (Sanitized)

<!-- /var/ossec/etc/ossec.conf -->
<active-response>
  <command>firewall-block</command>
  <location>local</location>
  <rules_id>100206</rules_id>
  <timeout>86400</timeout>
</active-response>

<active-response>
  <command>host-deny</command>
  <location>defined-agent</location>
  <agent_id><INTERNET_FACING_AGENT_ID></agent_id>
  <rules_id>5763</rules_id>
  <timeout>3888000</timeout>  <!-- 45 days -->
</active-response>

Chat Webhook Integration (Sanitized)

<!-- /var/ossec/etc/ossec.conf -->
<integration>
  <name>custom-mattermost</name>
  <hook_url><CHAT_WEBHOOK></hook_url>
  <level>8</level>
  <alert_format>json</alert_format>
</integration>

Validation and Evidence

Signals That Proved It Worked

Check	Before	After
Monitored agents	0	16 (all healthy)
Custom decoders	0	2 (firewall CSV, Zeek differentiation via rules)
Detection rules	Default only	60+ custom rules across 3 files
False positive alerts/day	Hundreds	<20 (suppression working)
Active response blocks	Manual only	Automated on flood detection
Alert latency to chat	N/A	<5 seconds

Validation Commands (Sanitized)

# Check agent status
/var/ossec/bin/agent_control -l
# Expected: 16 agents, all Active

# Test decoder parsing
echo '<SAMPLE_FIREWALL_LOG>' | /var/ossec/bin/wazuh-logtest
# Expected: Decoder pfsense-filterlog-fields extracts all fields

# Validate rule syntax
/var/ossec/bin/wazuh-analysisd -t
# Expected: No errors

# Check active response status
/var/ossec/bin/agent_control -L
# Expected: firewall-block and host-deny configured

# Verify chat integration
grep "custom-mattermost" /var/ossec/etc/ossec.conf
# Expected: Integration block present with webhook URL

Results

Metric	Outcome
Infrastructure Coverage	16 hosts monitored with unified SIEM
Custom Detection Rules	60+ rules across 3 rule files
Log Ingestion Paths	3 (agent 1514/tcp, syslog 514/udp, JSON file)
Detection Categories	C2 beaconing, DNS tunneling, DGA, port scanning, self-signed certs, honeypot probes, brute force, firewall floods
Active Response	Automated firewall blocking on flood detection
Alert Latency	<5 seconds to chat for level 8+ events
False Positive Reduction	Hundreds/day to <20/day via suppression rules

What I Learned

Wazuh's <field> tag defaults to OS_Match, not regex. OS_Match is simple wildcard matching. For pattern matching, you MUST specify type="pcre2". I wasted hours wondering why my regex patterns weren't matching.
The built-in JSON decoder catches everything starting with {. You cannot override it with custom decoders. Design your rules to differentiate JSON log sources by field presence, not decoder name.
<srcip> is surprisingly limited. No comma-separated CIDRs, no pipe alternation. You need one rule per CIDR. This bloats your rule file but there's no workaround.
Duplicate rule IDs fail silently. The second definition wins with no error, no warning. Use a clear numbering scheme and track assignments to avoid accidental collisions.
Wazuh's decoder loading order can't be changed. Built-in decoders in ruleset/ load before custom decoders in etc/. You can't preempt the JSON decoder.
Child decoders with <regex> replace parent field extraction. If a parent decoder extracts fields and a child decoder defines its own regex, the child's extraction replaces the parent's, not supplements it.
Frequency-based rules are powerful for detecting patterns. Port scanning, brute force, and flood attacks all have a frequency signature. Tune the timeframe and threshold carefully - too sensitive and you get false positives, too lenient and you miss attacks.
Suppression rules (level 0) are essential. Known-good infrastructure traffic will flood your alerts otherwise. CDN connections, VPN relays, cloud API calls - all need suppression rules.
Active response scripts receive JSON on stdin. Parse it carefully and validate the source IP before acting. A malformed log could trigger blocking the wrong IP.
Test with wazuh-logtest and wazuh-analysisd -t. These tools save hours of debugging. Test every decoder change and rule addition before deploying.

What I Would Improve Next

P0 (Do This Week)

File integrity monitoring rules - Add FIM for critical config files across all agents (/etc/passwd, /etc/shadow, sshd_config, crontab)
MITRE ATT&CK tagging - Add <mitre> tags to all custom rules for dashboard mapping and reporting

P1 (Do This Month)

Dashboard visualizations - Build custom Wazuh dashboards showing detection categories, top attackers, and alert trends
Suricata integration - Add signature-based IDS alongside Zeek's behavioral detection
Log retention policy - Implement archiving and rotation for long-term storage

P2 (Do This Quarter)

Vulnerability scanning - Enable Wazuh's vulnerability detection module
Incident response playbooks - Build automated response beyond IP blocking (isolate host, capture memory, notify on-call)
Windows detection rules - Add rules for PowerShell abuse, WMI persistence, suspicious registry changes
Threat intelligence feeds - Integrate IOC feeds for known-bad IP and domain matching

Common Failure Modes

"My regex pattern isn't matching in field rules" - You're probably missing type="pcre2". The default OS_Match only supports simple wildcards like * and ?, not full regex.
"My custom decoder isn't being used for JSON logs" - The built-in JSON decoder has priority. Use field presence in rules to differentiate, not custom decoders.
"Duplicate rule ID and alerts are wrong" - Wazuh silently uses the last definition of a duplicate ID. Check for collisions with grep -r "id=\"100123\"" /var/ossec/etc/rules/.
"srcip suppression rule isn't working with multiple CIDRs" - <srcip> only accepts a single CIDR. Create one rule per subnet.
"Alerts stopped arriving" - Check wazuh-manager service status, agent connectivity, and disk space. Full disk is a common silent killer.

Security Considerations

Multi-Layer Detection

Network layer: Zeek detects scanning, tunneling, and suspicious certificates
Perimeter layer: Firewall rules catch flood patterns and repeated blocks
Deception layer: Honeypot alerts on any connection attempt
Host layer: Agent-based monitoring for authentication and system events

Automated Response

Firewall auto-block removes human delay from flood response
SSH brute force blocking protects internet-facing services
45-day block duration for SSH attacks provides meaningful deterrence

False Positive Management

Suppression rules prevent alert fatigue from known infrastructure
Whitelists are specific (by CIDR, by domain pattern) not overly broad
Level thresholds ensure only significant events reach chat

Honeypot Integration

Any honeypot traffic is suspicious by definition - no legitimate reason to connect
Multi-service probes indicate active reconnaissance
High severity levels (12-14) ensure immediate attention

Runbook

If Alerts Stop Arriving

Check wazuh-manager service - systemctl status wazuh-manager
Verify agent connectivity - /var/ossec/bin/agent_control -l - look for disconnected agents
Check disk space - df -h /var/ossec - full disk stops logging
Review manager logs - tail -100 /var/ossec/logs/ossec.log - look for errors
Test log processing - Send test log through wazuh-logtest to verify decoder/rule chain

How to Add a New Agent

# On Wazuh server
/var/ossec/bin/manage_agents -a <NEW_AGENT_NAME> <AGENT_IP>
/var/ossec/bin/manage_agents -e <AGENT_ID>  # Extract key

# On new agent
/var/ossec/bin/manage_agents -i '<EXTRACTED_KEY>'
systemctl restart wazuh-agent

How to Test a New Rule

# 1. Add rule to local_rules.xml
# 2. Validate syntax
/var/ossec/bin/wazuh-analysisd -t

# 3. Test with sample log
echo '<SAMPLE_LOG>' | /var/ossec/bin/wazuh-logtest

# 4. If valid, restart manager
systemctl restart wazuh-manager

Rollback Procedure

# Revert rule changes
cp /var/ossec/etc/rules/local_rules.xml.backup /var/ossec/etc/rules/local_rules.xml

# Revert decoder changes
cp /var/ossec/etc/decoders/local_decoder.xml.backup /var/ossec/etc/decoders/local_decoder.xml

# Validate and restart
/var/ossec/bin/wazuh-analysisd -t
systemctl restart wazuh-manager

Appendix

Glossary

Term	Definition
Wazuh	Open-source SIEM platform for log analysis, intrusion detection, and compliance
Zeek	Network analysis framework that generates structured logs from traffic
OpenCanary	Honeypot daemon that emulates services and alerts on connections
DGA	Domain Generation Algorithm - malware technique using pseudo-random domains
C2	Command and Control - attacker infrastructure for controlling compromised hosts
Active Response	Automated actions triggered by SIEM rules (blocking, isolation, notification)
OS_Match	Wazuh's default string matching using simple wildcards (* and ?)
pcre2	Perl Compatible Regular Expressions - full regex support in Wazuh rules

MITRE ATT&CK Mapping

Technique ID	Name	Detection Rule Coverage
T1071.001	Application Layer Protocol: Web	Long-lived HTTPS connections, unusual User-Agents
T1071.004	Application Layer Protocol: DNS	DNS tunneling (long queries), high TXT query frequency
T1568.002	Dynamic Resolution: DGA	High-entropy subdomain detection, NXDOMAIN frequency
T1046	Network Service Scanning	Port scan detection via rejected connection frequency
T1110	Brute Force	SSH authentication failure frequency, active response blocking
T1021	Remote Services	Honeypot SSH/RDP connection detection
T1572	Protocol Tunneling	DNS query length analysis, connection duration analysis
T1573	Encrypted Channel	Self-signed certificate detection via Zeek SSL logs

Detection Logic Summary

Detection	Rule IDs	Data Source	Logic
Port scanning	100105	Zeek conn.log	Rejected connections >10 in 60s from same source
DNS tunneling	100115	Zeek dns.log	Query length >50 characters
DGA domains	100117	Zeek dns.log	Subdomain length >20 + high entropy pattern
Self-signed certs	100125	Zeek ssl.log	validation_status = "self signed"
C2 beaconing	100130	Zeek notice.log	Long_Connection notice from Zeek
Firewall flood	100206	pfSense filterlog	>50 blocks from same IP in 60s
Honeypot probe	100300-100310	OpenCanary/Zeek	Any connection to honeypot IP
SSH brute force	5763 (built-in)	auth.log	Multiple SSH failures from same source

Artifacts Produced

Custom Decoder: Firewall Log Parser - pcre2-based decoder for pfSense CSV filterlog format
Rule File: Network IDS Detection - 40+ rules for Zeek log analysis (connections, DNS, SSL, notices)
Rule File: Firewall Pattern Detection - 15+ rules for pfSense block analysis and flood detection
Rule File: Honeypot Alert Detection - 10+ rules for OpenCanary integration via Zeek
Active Response: Firewall Auto-Block Script - Adds attacking IPs to pfSense block table
Active Response: SSH Brute Force Blocker - iptables-based 45-day block for SSH attackers
Integration: Chat Webhook Alerting - Mattermost integration for level 8+ alerts

Bigfoot Sign-Off

You know how Bigfoot stays hidden? By watching everything and trusting nothing.

That's what a SIEM does. It sits in the forest of your infrastructure, eyes on every log, every connection, every authentication attempt. Most of it is just deer walking through - normal traffic, expected patterns, nothing to worry about. But every once in a while, something moves wrong. Steps where it shouldn't. Connects to the honeypot. Sends DNS queries that look like alphabet soup.

That's when you stop watching and start acting.

Sixty rules sounds like a lot until you realize how many ways attackers can move through a network. Scanning, tunneling, beaconing, brute forcing, lateral movement - each one needs its own tripwire. And the suppression rules? Those are just as important. A forest full of false alarms is a forest where real threats walk right past.

The auto-block is my favorite part. I've spent too many years manually blocking IPs while attackers moved faster than I could type. Now the SIEM sees the flood pattern, calls the firewall, and the attacker is gone before they know they've been spotted.

That's the dream: infrastructure that defends itself while I sleep.

Now if you'll excuse me, I have 60 rules that need MITRE ATT&CK tags. The paperwork never ends, even in the forest.

— Bigfoot Security Operations, ScottsLab "Watching the logs from the treeline since 2023"

Building your own SIEM? The field matching and srcip gotchas will bite you eventually. Hope this saves you the debugging time.
